DWA-X562Uus
Kirjeldus
The DWA-X562 Wireless AX1800 Dual Band PCI Express Adapter with Bluetooth 5.2 connects your desktop computer to a wireless network and provides a high-speed transmission. Once connected to your protected wireless network with the Internet access, you can enjoy browsing and chatting with your friends online.
Wi-Fi 6
The DWA-X562 supports 802.11ax technology (also known as Wi-Fi 6). OFDMA (Orthogonal Frequency Division Multiple Access) and uplink/downlink MU-MIMO (multi-user - multiple input multiple output) boost channel capacity and efficiency, enabling more clients to access the network.
Bluetooth 5.2 Connectivity
The DWA-X562 supports Bluetooth 5.2. This means you can connect Bluetooth devices like wireless headphones, controllers, keyboards and other devices to your computer without any additional adapters.
Better Speeds, Better Coverage
The DWA-X562 Wireless Adapter lets you connect to your wireless network with faster speeds in comparison with 802.11ac and 802.11n dual band adapters. The DWA-X562 supports operating in one of two frequency bands (2.4 GHz or 5 GHz) and provides maximum wireless speed up to 574 Mbps in the 2.4 GHz band and up to 1200 Mbps in the 5 GHz band. While operating in the 5 GHz band, the DWA-X562 allows to reduce an impact of interference from other wireless networks, improve a throughput and therefore increase the speed of streaming data, online games and VoIP calls.
The Benefits of PCI Express
PCI Express provides a high-bandwidth connection with superior performance over the legacy PCI interface. The PCI Express X1 interface allows you to connect the DWA-X562 to any PCIe slot in your computer, whether it is an x1, x4, x8, or x16 slot. The internal PCIe installation stays out of your way by fitting nicely in your computer case, keeping the antennas safely tucked away at the back.
Get Connected and Stay Connected
The DWA-X562 is designed for use in bigger homes and for users that demand higher networking performance. Maximize your wireless performance by connecting this adapter to a Wireless AX router and stay connected from virtually anywhere in your home. The DWA-X562 is also backward compatible with 802.11ax/ac/n/g/b/a technology, allowing you to connect to your older devices.
Robust Security Options
The DWA-X562 supports WPA3 encryption that provides a protected wireless network connection and protects transmitted data.
Põhiomadused
Interfaces
• PCI Express (PCIe) (Wi-Fi)
• F-USB (Bluetooth)
Installation Slot
• PCI Express x1/x4/x8/x16
Antenna
• Two 5 dBi detachable antennas
Requirements
Operating System
• Windows 10 (32/64)
Wireless Module Parameters
Standards
• IEEE 802.11a/b/g/n/ac/ax
• Bluetooth 5.2
Frequency Range
• 802.11b/g/n/ax: 2.4 GHz to 2.4835 GHz
• 802.11a/n/ac/ax: 5.15 GHz to 5.35 GHz, 5.725 GHz to 5.825 GHz*
Wireless Security
• 64/128-bit WEP
• WPA/WPA2/WPA3
Wireless Speed**
• IEEE 802.11a: 6, 9, 12, 18, 24, 36, 48 and 54 Mbps
• IEEE 802.11b: 1, 2, 5.5 and 11 Mbps
• IEEE 802.11g: 6, 9, 12, 18, 24, 36, 48 and 54 Mbps
• IEEE 802.11n: 6.5 to 300 Mbps (MCS0 to MCS15)
• IEEE 802.11ac: up to 866 Mbps
• IEEE 802.11ax (2.4 GHz): up to 574 Mbps
• IEEE 802.11ax (5 GHz): up to 1200 Mbps
Physical Parameters
Dimensions (L x W x H)
• 121 x 79 x 25 mm
Weight
• 87 g
Operation Conditions
Temperature
• Operating: 0 to 40• C
• Storage: -20 to 65• C
Humidity
• Operating: 10% to 90% non-condensing
• Storage: 5% to 95% non-condensing
Certifications
• CE
Sertifikaadid
Sidustooted
|
DWA-X562/E
(Rev. A1)
|
Wireless AX1800 Dual Band PCI Express Adapter
|
